Inspection Conveyor (500 & 1000mm)

Features

User friendly ‘soft touch’ LED membrane control panel
Modular design
Stability enhanced by ‘robust design’
Laser carved stainless steel side guides for superior quality and durability
Ergonomically designed arm rest
Smooth and parallel width adjustment
Multi-zone concept available upon request
Different lengths available upon request
Variable speed control
SMEMA compatible
Patented (SG Patent No.: 91261)

Description

This unit is used as a visual inspection station between SMD machines.

Specifications

Model No.	Size	Machine Dimension (mm) L x W x H	Fixed Point to Front Dimension (X)	Weight (Approximately)
NTM0501-M-500-1	M	500 x 570 x 985 mm	168 mm	45 kg
NTM0501-L-500-1	L	500 x 727 x 985 mm	168 mm	50 kg
NTM0501-M-1000-1	M	1000 x 570 x 985 mm	168 mm	70 kg
NTM0501-L-1000-1	L	1000 x 727 x 985 mm	168 mm	80 kg

Model No.	NTM0501-M-500-1
Size	M
Machine Dimension (mm) L x W x H	500 x 570 x 985 mm
Fixed Point to Front Dimension (X)	168 mm
Weight (Approximately)	45 kg

Model No.	NTM0501-L-500-1
Size	L
Machine Dimension (mm) L x W x H	500 x 727 x 985 mm
Fixed Point to Front Dimension (X)	168 mm
Weight (Approximately)	50 kg

Model No.	NTM0501-M-1000-1
Size	M
Machine Dimension (mm) L x W x H	1000 x 570 x 985 mm
Fixed Point to Front Dimension (X)	168 mm
Weight (Approximately)	70 kg

Model No.	NTM0501-L-1000-1
Size	L
Machine Dimension (mm) L x W x H	1000 x 727 x 985 mm
Fixed Point to Front Dimension (X)	168 mm
Weight (Approximately)	80 kg
